6” Mixed flow Borewell Submersible Pumps - TMS / TMS-L

6” Mixed flow Borewell Submersible Pumps 6” Mixed flow Borewell Submersible Pumps Mixed flow Borewell Submersibles
    rokade pumps
Product Features
rokade pumps Available in mixed flow impeller designs
rokade pumps Dynamically balanced LTB impellers with SS clads
rokade pumps Special LTB and nitrile rubber bearing bushes for high wear resistance and longer life
rokade pumps Bowls of high-grade cast iron Built in NRV with minimum friction
rokade pumps High quality seal rings and sand guards to protect motor from sand entry
rokade pumps Easily rewindable Squirrel cage motor of water-cooled, designed for 350 - 440 V (TMS) & 280 - 380 V (TMS-L), 50 Hz, AC power supply
rokade pumps Stainless steel stator shell to prevent rust formation
rokade pumps Specially designed carbon thrust bearing
rokade pumps High quality water-resistant polymer insulated wires for longer life even under adverse voltage conditions
rokade pumps Pressure diaphragm to compensate excess pressure due to heating up of filled water

Material Of Construction
Part Name Material Part Name Material
Impeller Gun metal Motor body AISI 304
Bowl FG 200 Bearing housing CI - FG 200
Pump shaft AISI 410 / 431 Motor shaft AISI 431 / 55C8
Sleeve AISI 410 Journal bush LTB-4
Bearing bush NBR Thrust bearing AISI 420 - Carbon
Non return valve AISI 304 - NBR Winding wire Polywrapped copper

Applications
» Domestic and community water supply.
» Water supply to high rise buildings, housing complexes, bungalows and Industries
» Irrigation of farms
» Cattle and poultry farms
» Dairies
» Cooling water circulating systems
» Fire fighting systems
» Fountains.
