Improved efficiency and minimal maintenance by
having the set operated on a common shaft.
Dynamically balanced rotors and impellers ensure
vibration free performance and enhanced life.
Easy handling with an eye bolt.
Aluminium pressure die-cast rotors press-fitted onto
precision machined motor shafts.
Accurate control on the uniformity in air gap to
minimize vibration.
Deep groove ball bearings packed with right quantity
of special grease ensures long life.
Rigorous quality control testing at every stage of
manufacturing ensures higher efficiency.
Low temperature with Class A insulation ensures long
trouble free operation.
Squirrel-cage motor of TEFC type designed to operate
in a wide voltage range 350 - 440 V, 50Hz, AC
power supply.
Material Of Construction
Part Name
Material
Part Name
Material
Impeller
CI FG 200
Gland / packing rope
AISI 410 / Grease
graphited cotton
Casing
CI GR 180
Motor body
CI GR 180
Sleeve
AISI 410
Shaft
45C8 / 55C8
Stuffing box
CI GR 180
Winding wire
Enameled copper
Applications
» Irrigation » Drinking water supply » Industrial water supply » Cooling water circulating systems.
