Single Phase Centrifugal Monoblock Pumps - HCS / TCS |
|
| Product Features |
 |
Easy installation and low operating cost. |
|
Improved efficiency and minimal maintenance by
having the set operated on a common shaft. |
|
Dynamically balanced rotors and impellers ensure
vibration free performance and enhanced life. |
|
Easy handling with an eye bolt. |
|
Aluminium pressure die-cast rotors press-fitted onto
precision machined motor shafts. |
|
Deep groove ball bearings packed with right quantity
of special grease ensure long life. |
|
Rigorous quality control testing at every stage of
manufacturing ensures higher efficiency. |
|
Squirrel cage motor of TEFC type designed to operate
in a wide voltage range180-240 V, 50Hz, AC power
supply. |
|
| |
| Material Of Construction |
| Part Name |
Material |
Part Name |
Material |
| Impeller |
AISI 304 / Gunmetal /
CI FG 200 |
Mechanical seal |
Carbon / Ceramic |
| Casing |
CI GR 180 |
Motor body |
CI GR 180 |
| Sleeve |
AISI 410 (1.5/2.0hp) |
Shaft |
AISI 410 / 45C8 |
| Flanges |
CI GR 180 |
Winding wire |
Enameled copper |
|
| |
| Applications |
| » Domestic and community water supply |
| » Water supply to high-rise buildings, housing, complexes, bungalows and
industries |
| » Irrigation of farms |
| » Cattle and poultry farms |
| » Dairies |
| » Cooling water circulating systems |
| » Fire fighting systems |
| » Fountains. |
